GEEKOM A9 Max 2026: Updated Mini-PC with AMD Ryzen AI 9 HX 470 Processor

Following last year’s 2025 version review, we now have the GEEKOM A9 Max 2026 for its review. This latest update incorporates the cutting-edge AMD Ryzen AI 9 HX 470 processor, retaining the integrated AMD Radeon 890M graphics from its predecessor. It also comes equipped with 32GB of DDR5 RAM, a 2TB SSD, and exceptional connectivity, as we will explore throughout this review.

The GEEKOM A9 Max 2026 is presented in a compact white cardboard box, slightly larger than the mini-PC itself. The front of the box showcases a silver silhouette of the device, while the rear highlights its key features.

Upon opening the box, the mini-PC is found on the first level, protected by a cardboard frame and a plastic bag. Beneath this, a well-organized set of accessories is located.

Included accessories are an HDMI cable for monitor connection, a VESA 100 mount for easy monitor attachment, and a compact 120W power adapter (19V / 6.32A) that complements the mini-PC’s small form factor.

Technical Specifications of the GEEKOM A9 Max 2026

Design and Connectivity of the GEEKOM A9 Max 2026

The GEEKOM A9 Max 2026 is a compact mini-PC housed in an aluminum chassis with dimensions of just 135 x 132 x 46.9 mm (length, width, height). Its small size makes it easily portable and it occupies minimal desk space.

Front Connectivity

One of the GEEKOM A9 Max 2026’s strong suits is its connectivity. The front panel offers four USB 3.2 Gen2 ports (up to 10 Gbps), with one port providing always-on power for device charging even when the PC is off. Additionally, there’s a 3.5mm TRRS jack for headphones and microphone, and a power button with an integrated LED indicator.

Kensington Lock and SD 4.0 Card Reader

The left side features an SD 4.0 card reader, useful for photographers and videographers, as well as for other portable devices. The right side includes a Kensington lock connector for added security.

Rear Connectivity

The rear of the GEEKOM A9 Max 2026 houses the majority of its connectivity. Alongside the power connector, there is an HDMI 2.1 FRL video output capable of 4K at 60 Hz and one of the two USB4 ports. Each USB4 port supports data transfer up to 40 Gbps, DisplayPort video output, and PD charging for the left port. The rear also includes a 10 Gbps USB 3.2 Gen2 port, a classic USB 2.0 port, and two RJ-45 connectors. These connect to dual Realtek RTL8125 2.5 GbE network interfaces, complemented by a Realtek MT7925 Wi-Fi 7 wireless card with Bluetooth 5.4, ensuring comprehensive and up-to-date networking capabilities.

The underside of the GEEKOM A9 Max 2026 features four rubber feet for stability. Removing them reveals four screws that provide access to the interior.

Upon opening the device, a metal plate is visible, covering the motherboard and housing the WiFi antennas. Removing this plate reveals the compact motherboard PCB, featuring two SO-DIMM DDR5 memory slots (one occupied), a free M.2 PCIe 4.0 2230 slot, and an occupied M.2 PCIe 4.0 2280 slot.

On the opposite side of the motherboard, the processor is located, along with the IceBlast 3.0 cooling system responsible for maintaining optimal temperatures.

Hardware of the GEEKOM A9 Max 2026

AMD Ryzen AI 9 HX 470 Processor

The core of the GEEKOM A9 Max 2026 is the AMD Ryzen AI 9 HX 470 processor, a latest-generation model with a hybrid architecture from the Gorgon Point family. It features 4 Zen 5 cores running at up to 5.2 GHz and 8 Zen 5c cores at up to 3.3 GHz, all with hyper-threading for a total of 24 threads. It also boasts 12 MB of L2 cache and 24 MB of L3 cache, along with a 55 TOPS AMD Ryzen AI NPU for accelerating AI-based tasks.

32GB DDR5 RAM at 5,600 MHz

The GEEKOM A9 Max 2026 is equipped with a single module of 32GB DDR5 RAM running at 5,600 MHz. This occupies one of the two available SO-DIMM slots, meaning it does not leverage dual-channel configuration for maximum performance.

Integrated AMD Radeon 890M Graphics

The AMD Ryzen AI 9 HX 470 processor includes integrated AMD Radeon 890M graphics with 16 cores operating at 3.1 GHz. These graphics utilize 4GB of system RAM as VRAM, which is sufficient for good performance in gaming and other graphics-intensive tasks.

M.2 PCIe 4.0 SSD Storage

The GEEKOM A9 Max 2026 features two PCIe 4.0 slots on its motherboard: one 2280 format and one 2230 format. The 2280 slot houses a 2TB Kingston OM8TAP42048K1 SSD, offering excellent performance with sequential read speeds of up to 6 GB/s and sequential write speeds around 5.5 GB/s, more than adequate for most uses.

Performance Tests

Upon powering on the GEEKOM A9 Max 2026, the pre-installed Windows 11 operating system requires an initial setup, which may take around half an hour for updates and requires a Microsoft account.

Testing the AMD Ryzen AI 9 HX 470 processor in Cinebench reveals impressive performance for such a compact device, comparable to mid-range desktop processors. Considering its 54W TDP compared to over 100W for mid-range desktop CPUs, its efficiency is remarkable.

However, the 32GB DDR5 RAM at 5,600 MHz does not deliver expected performance due to its single-channel configuration, limiting its potential by 50%. Previous analyses of models with dual-channel RAM showed nearly double the transfer rates, highlighting the need for a second RAM module.

In photo editing tasks, the GEEKOM A9 Max 2026 proves to be a capable machine. However, video editing performance is again hampered by the single-channel RAM configuration.

Similar conclusions can be drawn for AI tasks, where sufficient memory bandwidth is crucial for high performance.

The primary bottleneck arises during gaming. The AMD Radeon 890M integrated graphics rely on system RAM as VRAM, and the reduced bandwidth significantly impacts performance. Comparing to a dual-channel configuration on the previous HX370 model, gaming performance sees approximately a 50% increase.

In gaming, the device still offers enough power to enjoy modern titles at Full HD resolution with minimal graphics settings. While achieving over 60 FPS is possible, the performance drop compared to a dual-channel setup is noticeable.

A significant strength of the brand, and evident in the GEEKOM A9 Max 2026, is its thermal and acoustic management. The IceBlast 3.0 cooling system effectively keeps the demanding AMD Ryzen AI 9 HX 470 processor cool. Crucially, it achieves this with remarkably low noise levels, around 44 dBA at full load, which is not disruptive.

Conclusions of the GEEKOM A9 Max 2026

In conclusion, the GEEKOM A9 Max 2026 stands out with its attractive, compact aluminum chassis and impressive power. It houses the AMD Ryzen AI 9 HX 470 processor with integrated AMD Radeon 890M graphics, positioning it as a high-performance mini-PC. However, the single RAM module significantly hinders its overall performance, a surprising oversight for a device in this class. Despite this, its connectivity is exceptional, featuring two USB4 ports (up to 40 Gbps) and an excellent networking combination with Wi-Fi 7 and dual 2.5 GbE ports.

Availability and Price

The GEEKOM A9 Max 2026 can be purchased from the official website or Amazon for approximately 1,565 euros. Utilizing the discount code CINFA9M8 offers an 8% discount. This price is high for a high-performance machine, especially considering the necessity of adding a second 32GB DDR5 RAM module, which costs around 350 euros. However, this reflects the current market reality, with AI driving up the prices of RAM and SSDs.

From El Chapuzas Informático, we award the Gold Award to the GEEKOM A9 Max 2026 barebone.
